PEB Fabrication in Vadodara, Gujarat
Factory-controlled fabrication of primary and secondary steel framing for pre-engineered buildings — cut, welded, drilled and painted to drawing.
What PEB Fabrication Means at Matrix PEB
PEB fabrication is where a structural drawing becomes steel you can bolt together. At our Fajalpur works near Vadodara we fabricate the complete building kit — tapered built-up columns and rafters, end-wall framing, Z and C purlins, girts, eave struts, bracings, base plates and all connection hardware.
Every member is fabricated to the approved shop drawing, not to a catalogue size. Web and flange plates are profile-cut to the bending-moment diagram, so steel sits where the load is and nowhere it isn't. That is the whole economic argument for a pre-engineered building, and it only holds if the fabrication is genuinely engineered rather than standardised.
Welding is done on jigs with controlled root gaps and verified fit-up. Holes are drilled to template so that connections land first time at site — a shed that needs field drilling has already lost the time it was supposed to save.
What’s Included
Built-up primary framing
Tapered columns and rafters fabricated from profile-cut plate, welded on jigs with automatic and semi-automatic processes for consistent penetration.
Cold-formed secondary members
Z and C purlins, girts, eave struts and sag rods roll-formed to the required section depth and gauge for your span and wind loading.
Surface preparation & painting
Shot blasting or mechanical cleaning followed by a primer and finish system selected for the site's exposure — inland, coastal or chemical.
Match-marking & dispatch lists
Every member is match-marked to the erection drawing and dispatched against a packing list, so site knows exactly what arrived and where it goes.
Quality records
Material test certificates, dimensional checks and weld inspection records maintained per project and handed over with the documentation set.
Connection hardware
High-tensile bolts, nuts, washers and anchor bolts supplied to grade with the structure, so nothing on site waits for hardware procurement.
PEB Fabrication Across Gujarat & Madhya Pradesh
We deliver peb fabrication from our Vadodara works to industrial estates across the region. Pick your city to see how we work there.
PEB Fabrication — Frequently Asked Questions
How long does PEB fabrication take?
For a typical industrial shed of 1,000–2,000 m², fabrication runs about 3–5 weeks after drawing approval, depending on the current shop load and how much of the steel is in stock. Larger multi-bay structures are fabricated and dispatched in phases so erection can begin on the first bay while later bays are still in the shop.
Do you fabricate to IS standards?
Yes. Design follows IS 800 for steel structures, with IS 875 for dead, live and wind loading and IS 1893 where seismic loading applies. Material is procured against test certificates and fabrication follows the approved shop drawings.
Can you fabricate from drawings supplied by our consultant?
Yes. We fabricate to client or consultant drawings, and we will also review them and flag anything that would cause a fit-up problem at site before cutting begins. If you would rather we handle the design too, our in-house engineering team can take it from the load brief onwards.
What steel grade do you use?
Primary framing is normally fabricated from IS 2062 E250 or E350 plate depending on the design, with cold-formed secondary members in high-yield galvanised or black steel as specified. The grade is confirmed at the design stage and recorded on the drawings.
